| Home |
| Sum: | Checksum (via simple byte addition) |
| Copy: | How the image was created. D=direct (e.g. from EPROM programmer) C=computer (using computer [e.g. DEBUG software]) |
| Source: | Person at the VCFF (or at phantom.sannata.ru) who supplied the image. Note that the supplier isn't necessarily the same person who created the image. |
| Make | Model | Function | Year | Code Version | Socket | Data Type | Sum | Chip Type | Size | Copy | Source | Link | Description/Comment |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ??? | ??? | 8-bit EGA card | '88 | 2.4 | U9 | BIOS | 2C5300 | M27256-2 | 32 KB | D | IdeaFix | Download | Contains "GEMINI VC-001 EGA BIOS, Version V2.4". Main chip is a Gemini GC201. |
| ??? | ??? | 8-bit EGA card | '85 | 1.6A | U1 | BIOS | 289400 | NM27C256 | 32 KB | D | IdeaFix | Download | Contains "EGA BIOS V1.6a COPYRIGHT Award Software Inc". Main chip is a CITYGATE D10. |
| ??? | ??? | 8-bit floppy controller | '86 | 1.60 | U7 | BIOS | 1BE500 | ? | 8 KB | ? | romanon | Download | Contains "HFDC card Ver 1.60 (C) HSIN-LIN COMPUTER CO., LT". Main chip is a UM8272A. |
| ??? | AVGA1-A11 | 16-bit VGA card | '90 | B | U5 | BIOS | 44C6DE | [27256] | 32 KB | D | alecv | Download | See note 12. Click here to see the bytes rearrranged. |
| ??? | FA-100 | 8-bit floppy controller | '88 | 1.0 | U5 | BIOS | 0D7200 | M2764A | 8 KB | D | Robin4 | Download | Contains strings "FAX-100" and "Bios Ver. 1.0 (June/15/1988)". "FA-100" on ROM sticker. |
| ??? | MCT-VGA-16 | 16-bit VGA card | '91 | 1.04A | ? | BIOS | 00083B | [27256] | 32 KB | D | SomeGuy | Download | Contains "TDVGA 3588 BIOS Version V1.04A". Main chip is a TD3588A |
| ??? | MT-8813 | 8-bit multifunction card | Use ROM for Sunix Sun-6301 | ||||||||||
| ??? | PE-510D | 8-bit floppy controller | ? | ? | U4 | BIOS | 17CA00 | HN482764G-4 | 8 KB | D | modem7 | Download | Contains strings "PE-510B-N" and "PE-510C-EXT". Main chip is a DP8473V. |
| ??? | SSI-011SF | 16-bit SCSI controller | '90 | 6.02 | U3 | BIOS | 10BBFF | [2764] | 8 KB | D | alecv | Download | Appears to be a clone of a Future Domain TMC-950. See note 4. |
| ??? | VTI-XTB | 8-bit IDE-XT controller | '88 | 1.7 | U3 | BIOS | 166800 | 27C64A-20 | 8 KB | D | SunDown79 | Download | Card possibly made by 'V & V System'. |
| Abell C&C Corp. | EN-100-1 | 8-bit network card | '89 | V1.2e | U15 | Boot | 17C400 | [2764] | 8 KB | D | alecv | Download | NE-1000 compatible card. IPX boot ROM. |
| Acculogic | SIDE-1/16 | 8-bit IDE-XT controller | D | ? | Download | Pointer to ibm-pc.org | |||||||
| Adaptec | ACB-2070A | 8-bit RLL controller | '85 | 17A 7C |
1. BIOS 2. Firmware |
0BF400 0B137E |
[2764] [2764] |
8 KB 8 KB |
D D |
modem7 modem7 |
Download Download |
"BIOS 401402-00 A 0 1985" on 17A ROM sticker. "401401-00 C 0 1985" on 7C ROM sticker. |
|
| Adaptec | " | " | '86 | ? ? |
1. BIOS 2. Firmware |
0BB800 0B1A75 |
[2764] [2764] |
8 KB 8 KB |
D D |
Robin4 Robin4 |
Download Download |
"ADAPTEC INC BIOS 405702-00 A Copyright 1986" on ROM sticker. "ADAPTEC INC 405701-00 B Copyright 1986" on ROM sticker. |
|
| Adaptec | ACB-2072 | 8-bit RLL controller | '87 | U11 | BIOS | 0E3000 | [2764] | 8 KB | C | TMA-1 | Download |
"408100 H, BIOS (C) 1987, 411503-00A" on U11 ROM sticker. |
|
| Adaptec | ACB-2322D | 16-bit ESDI controller | '90 | U11 U14 |
1. BIOS 2. Microcode |
0300 08BE |
NMC27C128Q-200 D27C128 |
16 KB 16 KB |
D D |
modem7 modem7 |
Download Download |
"439201-00 D BIOS 0300" on U11 ROM sticker. "437302-00 C MCODE 08BE" on U14 ROM sticker. |
|
| Adaptec | AHA-1542C | 16-bit SCSI controller | '93 | U15 U5 |
1. BIOS 2. Microcode |
144C A3C2 |
NM27C256Q-150 NM27C256Q-150 |
32 KB 32 KB |
D D |
modem7 modem7 |
Download Download |
"534201-00 D BIOS 144C" on U15 ROM sticker. "144C" bit is checksum. See note 6. "534001-00 D MCODE A3C2" on U5 ROM sticker. "A3C2" bit is checksum. |
|
| Adaptec | AHA-1542CF | 16-bit SCSI controller | '93 | U15 U16 |
1. Microcode 2. BIOS |
563D C38D |
M27C256B-15 M27C256B-15 |
32 KB 32 KB |
D D |
sequoia sequoia |
Download Download |
"553801-00 C MCODE 563D" on U15 ROM sticker. "563D" bit is checksum. See note 2. "553601-00 C BIOS C38D" on U16 ROM sticker. "C38D" bit is checksum. |
|
| Adaptec | AHA-1542CP | 16-bit SCSI controller | '95 | U7 U12 |
1. BIOS 2. Microcode |
A91E 17C9 |
[27256] [27256] |
32 KB 32 KB |
D D |
modem7 modem7 |
Download Download |
"908501-00 D BIOS A91E" on U7 ROM sticker. "A91E" bit is checksum. See note 2. "908301-00 F MCODE 17C9" on U12 ROM sticker. "17C9" bit is checksum. |
|
| Adaptec | AVA-1515 | 16-bit SCSI controller | '93 | 1.20L | U5 | BIOS | 4700 | [27C128] | 16 KB | D | alecv | Download | Based on the AIC-6360 chip. "585201-00 A BIOS 4700" on U5 ROM sticker. "4700" bit is 16-bit checksum. |
| Aquarius Systems | AVGA-1DC | 16-bit VGA card | '91 | ? | U23 | BIOS | 2BF100 | [27256] | 32 KB | C | Krille | Download | Main chip: WD90C30 |
| ASC | ASC-88 | 8-bit SCSI card | '91 | 4.0N | U14 | BIOS | 0E5700 | TMS27C64-1 | 8 KB | D | alecv | Download | Contains strings "Advanced Storage Concepts, Inc" and "ver 4.0N" |
| AST | AST-3G | 8-bit EGA card | '85 | V2.015 | U29 | BIOS | 162900 | DQ27128 | 16 KB | D | modem7 | Download | Contains string "Copyright 1985 AST Research, Inc. V2.015" |
| AT&T | PC 6300 | IBM PC clone | '84 | 1.1 | 6F 6H |
BIOS BIOS |
0B39C0 0BD240 |
[2764] [2764] |
8 KB 8 KB |
D D |
Pixil Pixil |
Download Download |
High ROM. "1.1" and "H" on ROM sticker. Low ROM. "1.1" and "L" on ROM sticker. |
| AT&T | " | " | '86 | 1.43 | See 'Olivetti M24' below | ||||||||
| AT&T | " | " | '87 | 1.44 | See 'Olivetti M24' below | ||||||||
| ATI | EGA Wonder 800 | 8-bit EGA card | '87 | 1.03 | BIOS | 2E9900 | [27256] | 32 KB | D | nztdm | Download | ||
| ATI | EGA Wonder 800+ | 8-bit EGA card | '89 | N1.00 | BIOS | 2A6900 | 27C256-20 | 32 KB | ? | per | Download | ||
| ATI | Graphics Solution Plus |
8-bit video card | U3 | Font ? | 07E065 | 9864ADS | 8 KB | D | sequoia | Download | Same ROM content as the ATI Small Wonder Graphics Solution V1 | ||
| ATI | Mach64 ISA | 16-bit VGA card | '96 | 112-28124-102 112-28125-102 |
U1 U71 |
BIOS BIOS |
18F622 1885DE |
[27128] [27128] |
16 KB 16 KB |
D D |
per per |
Download | Combined contents includes "ATI MACH64, ISA BIOS P/N 112-28124-102" |
| ATI | Small Wonder Graphics Solution V1 |
8-bit video card | U1 | Font ? | 07E065 | S27C64A-20N | 8 KB | D | sequoia | Download | Version 1 of the card. Same ROM content as the ATI Graphics Solution Plus | ||
| ATI | VGA Wonder+ | 16-bit VGA card | '90 | V1M-1.03/70 | U11 U12 |
BIOS BIOS |
2ABB18 2A0AE8 |
SEEC 27C256-20 SEEC 27C256-20 |
32 KB 32 KB |
D D |
Robin4 Robin4 |
Download Download |
"VGA WONDER+ V1M-1.03/70 EVEN" on U11 ROM sticker "VGA WONDER+ V1M-1.03/70 ODD" on U12 ROM sticker |
| ATI | VGA Wonder XL | 16-bit VGA card | '91 | 11201122020 | U16 U17 |
BIOS BIOS |
2F20C6 2F453A |
27C256-15 27C256-15 |
32 KB 32 KB |
D D |
MikeS MikeS |
Download Download |
"Even: 11201122020 (c) 1991" on U16 ROM sticker "Odd : 11211122020 (c) 1991" on U17 ROM sticker |
| ATI | VGA Wonder XL24 | 16-bit VGA card | '92 | 112-14318-102 | U16 U17 |
BIOS BIOS |
2FD86D 2FAE93 |
[27256] [27256] |
32 KB 32 KB |
D D |
per per |
Download Download |
"112-14318-102 EVEN" and "VGA WONDER XL24" on ROM sticker "112-14319-102 ODD" and "VGA WONDER XL24" on ROM sticker |
| BusLogic | BT-545S | 16-bit SCSI controller | '92 | 4.5 3.31 |
U15 U2 |
1. BIOS 2. Firmware |
17CA00 493100 |
[27128] [27256] |
16 KB 32 KB |
D D |
modem7 modem7 |
Download Download |
"5002026-4.50" on U15 ROM sticker. Under EPROM, PCB has "27128" on it. "5002005-3.31" on U2 ROM sticker. Under EPROM, PCB has "27256" on it. |
| Centos | [ see JDR ] | [ see JDR ] | |||||||||||
| Cirrus Logic | CL-GD5422 | 16-bit VGA card | '92 | 1.00d | U2 | BIOS | 2DC400 | [27256] | 32 KB | D | SomeGuy | Download | See note 12. Contains "CL-GD540X/542X VGA BIOS Version 1.00d". |
| Columbia Data Products |
1600VP | IBM PC clone | '83 | 4.33 | U116 U115 U114 |
BIOS BIOS BIOS |
063439 073B3D 06FE38 |
AM2732DC AM2732DC AM2732DC |
4 KB 4 KB 4 KB |
D D D |
SomeGuy SomeGuy SomeGuy |
Download Download Download |
"MPC4.33 U45" on U116 ROM sticker "MPC4.33 U46" on U115 ROM sticker "MPC4.33 U47" on U114 ROM sticker |
| Columbia Data Products |
MPC 1600-1 | IBM PC clone | '83 | 4.34 | U45 U46 U47 |
BIOS BIOS BIOS |
063392 073CCD 071233 |
M2732AF M2732AF M2732AF |
4 KB 4 KB 4 KB |
D D D |
SomeGuy SomeGuy SomeGuy |
Download Download Download |
"MPC4.34 U45" on U45 ROM sticker "MPC4.34 U46" on U46 ROM sticker "MPC4.34 U47" on U47 ROM sticker |
| Commodore | PC10-III | IBM PC clone | '90 | 4.41 | ? | BIOS | 26EC00 | [27256] | 32 KB | ? | archeocomp | Download | Many Commodore ROM images at http://mhv.bplaced.net/cbmROMs/cbmROMs.php |
| Compaq | Portable | IBM PC clone | '82 | B | ? | BIOS | 0E7ECF | [2764] | 8 KB | ? | rvdbijl | Download | WARNING: Does not support BIOS expansion ROMs |
| Compaq | " | " | '85 | F | ? | BIOS | 0EB6C1 | [2764] | 8 KB | D | FixUntilBroken | Download | |
| Compaq | " | " | U35 | Decode | nztdm | Download | RAM Decoder PROM | ||||||
| Compaq | Portable Plus | IBM PC clone | '83 | C | U40 U47 |
BIOS BIOS |
0EA8AC 0EA8AC |
[2764] [2764] |
8 KB 8 KB |
D D |
SomeGuy SomeGuy |
Download | Both ROMs have the same contents. Also suitable for Portable. |
| Compaq | " | " | U35 | Decode | nztdm | Download | RAM Decoder PROM | ||||||
| Compaq | VDU card for Portable Plus |
'83 | ? | U41 | Font | 06EDB9 | AM9265 | 8 KB | D | Jafir | Download | 100519-001 REV B / Photo of card in download zip | |
| Compaq | HDD card for Portable Plus |
'83 | ? | U36 | BIOS | 1B2E00 | M3864-15 | 8 KB | D | Jafir | Download | 100693-4 / Photo of card in download zip | |
| Compaq | Portable II | IBM AT clone | '86 | G | U29 U28 |
BIOS BIOS |
239E72 225C8E |
[27128] [27128] |
16 KB 16 KB |
D D |
nztdm nztdm |
Download Download |
106580-001 / ODD byte 106581-001 / EVEN byte |
| Compaq | " | " | '88 | P.1 | U29 U28 |
BIOS BIOS |
1D3767 1D2699 |
[27128] [27128] |
16 KB 16 KB |
D D |
nztdm nztdm |
Download Download |
109739-001 / ODD byte 109740-001 / EVEN byte |
| Compaq | " | " | '89 | S.1 | U29 U28 |
BIOS BIOS |
1CF93B 1D29C5 |
D27128A D27128A |
16 KB 16 KB |
D D |
nztdm nztdm |
Download Download |
109739-003 / ODD byte 109740-003 / EVEN byte |
| Compaq | Portable III | IBM AT clone | '87 | K | ? ? |
BIOS BIOS |
1AECD2 1ABA2E |
[27128] [27128] |
16 KB 16 KB |
? ? |
T-Squared T-Squared |
Download Download |
106778-002 / ODD byte 106779-002 / EVEN byte |
| Compaq | " | " | '88 | P.2 | ? ? |
BIOS BIOS |
51EA61 51DF9F |
[27128] [27128] |
16 KB 16 KB |
? ? |
here | Download Download |
109737-001 / ODD byte 109738-001 / EVEN byte |
| Compaq | " | " | '88 | R.2 | ? ? |
BIOS BIOS |
51B0ED 51CC13 |
[27128] [27128] |
16 KB 16 KB |
? ? |
here | Download Download |
109737-002 / ODD byte 109738-002 / EVEN byte |
| Compaq | Portable 486 | Download | Pointer to bitsavers | ||||||||||
| Compaq | DeskPro | IBM PC clone | '85 | G | U21 | BIOS | 0EBD00 | [2764] | 8 KB | D | dhau | Download | 105681-001 / See final page of this. |
| Compaq | " | " | '87 | J | U21 | BIOS | 0EA900 | [2764] | 8 KB | D | Jafir | Download | 106265-002 / See final page of this. |
| Compaq | Deskpro 386 | Download | Pointer to bitsavers | ||||||||||
| Compaq | SLT/286 | IBM AT clone | '89 | J.2 | ? ? |
BIOS BIOS |
417127 41AFD9 |
[27256] [27256] |
32 KB 32 KB |
D D |
nztdm nztdm |
Download Download |
106778-001 / ODD byte 106779-001 / EVEN byte |
| Compaq | SLT 386s/20 | IBM AT clone | '90 | ? | ? ? |
BIOS BIOS |
3835C7 386139 |
N27C256-150 N27C256-150 |
32 KB 32 KB |
D D |
nztdm nztdm |
Download Download |
118283-005 / ODD byte 118284-005 / EVEN byte |
| Conion Electronics | PC8008F | 8-bit SCSI controller | '93 | 8.2 | U1 | BIOS | 125D00 | NMC27C64Q | 8 KB | D | alecv | Download | Appears to be a clone of a Future Domain TMC-850M. Uses same ROM. |
| Corel | LS2000 | 8-bit SCSI controller | '91 | 1.65 | U2 | BIOS | 086000 | [2764] | 8 KB | D | Robin4 | Download | Contains "Ver 1.65" and "(C)1991 COREL Systems Corp." |
| Corona/Cordata | Corona PPC-21 | Portable computer | '84 | 3.10 | ? | BIOS | 0E0B53 | [2764] | 8 KB | D | rvdbijl | Download | |
| Corona/Cordata | Corona PPC-21 | Portable computer | '84 | 4.23CG | ? | BIOS | 191631 | [27128] | 16 KB | ? | here | Download | A basic boot test in a PC-400 by rvdbijl suggests that this image is okay. |
| Corona/Cordata | Cordata PC-400 | Desktop computer | '86 | 4.33C | ? | BIOS | 1F31B1 | [27128] | 16 KB | D | rvdbijl | Download | |
| CTT | IT-805 | 8-bit MFM controller | '87 | 1.22 | U11 | BIOS | 0CE500 | [2764] | 8 KB | D | haglebu | Download | Contains "SUNTEK hard disk BIOS for 8088 system, version 1.22" and "SUNIX SUN-3100 VERSION 4.01" |
| D-Link | DE-150 | 8-bit network card | '88 | 2.10 | U1 | Boot | 0C0400 | D2764A | 8 KB | D | alecv | Download | Contains "D-Link DE-150 Ethernet BootROM Driver V2.10" |
| Dell | System 200 | IBM AT clone | '92 | 3.10 A12 | ? ? |
BIOS BIOS |
558000 557800 |
M27C256B-15 M27C256B-15 |
32 KB 32 KB |
D D |
roadrash roadrash |
Download Download |
Contains: "80286 ROM BIOS PLUS Version 3.10 A12" and "Dell System 200" and "02/14/92" |
| Dell | " | " | ? | ? | ? | Keyboard controller |
01B600 | D8742 | 2 KB | D | roadrash | Download | Keyboard controller chip on motherboard. "20575 B47-00" appears on its sticker. |
| DTC | 5150BX | 8-bit MFM controller | '83 | ? | 3A | BIOS | Has "5150BX" printed at bottom-left. | ||||||
| DTC | 5150BX 1 | 8-bit MFM controller | '83 | BXD05 | 3A | BIOS | First major revision of the card. Has "5150BX 1" printed at bottom-left. | ||||||
| DTC | 5150BX 2 | 8-bit MFM controller | '85 | BXD06 | 7E | BIOS | 16A000 | [2764] | 8 KB | D | modem7 | Download | Second major revision of the card. Has "5150BX 2" printed at bottom-left. |
| DTC | 5150BX 3 | 8-bit MFM controller | |||||||||||
| DTC | 5150BX 4 | 8-bit MFM controller | |||||||||||
| DTC | 5150CX | 8-bit MFM controller | '86 | BXD07 | 3F | BIOS | 16DB00 | [2764] | 8 KB | D | sequoia | Download | BXD07 also seen on a 5150CI |
| DTC | 5150CRH | 8-bit MFM controller | '87 | CXD03A | 6B | BIOS | 0BD600 | [2764] | 8 KB | D | modem7 | Download | |
| DTC | " | " | '88 | CXD04A | " | " | 0BFE00 | [2764] | 8 KB | D | alecv | Download | (photo) |
| DTC | 5150X | 8-bit MFM controller | '88 | CXD21A | 6B | BIOS | 0C3E00 | [2764] | 8 KB | D | modem7 | Download | |
| DTC | " | " | " | CXD23A | " | " | 0C5300 | [2764] | 8 KB | D | modem7 | Download | |
| DTC | 5160X | 8-bit RLL controller | '88 | CRD18A | 6B | BIOS | 0C1900 | [2764] | 8 KB | D | modem7 | Download | |
| DTC | 7187 | 16-bit RLL controller | '88 | CRN15A | 6B | BIOS | 15CE00 | D27128A | 16 KB | D | Tronix | Download | |
| DTC | 7287 | 16-bit RLL controller | '88 | CRN15A | 11B | BIOS | 15CE00 | NMC27C128Q-200 | 16 KB | D | modem7 | Download | |
| DTC | ? | ? | '87 | CRL02A | ? | BIOS | 103D00 | ? | 16 KB | ? | Tronix | Download | |
| DTC | ? | ? | '88 | CRH16A | ? | BIOS | 000140 | ? | 16 KB | ? | Tronix | Download | |
| DTK | PII-151 | 8-bit floppy controller | '86 | 1.4 | U15 | BIOS | 044F00 | M2764A | 8 KB | ? | Kazblox | Download | Contains "DTK FDC DRIVER BIOS (C) COPYRIGHT 1986" and "Ver. 1.04" |
| DTK | PII-151B | 8-bit floppy controller | '86 | 1.06B | K2 | BIOS | 044B00 | M2764A | 8 KB | ? | Robin4 | Download | Contains "DTK FDC DRIVER BIOS (C) COPYRIGHT 1986" and "Ver. 1.06B" |
| Eagle Computer | PC Spirit | IBM PC clone | '83 | 1.9 | U1101 U1103 |
BIOS BIOS |
0D8C00 189200 |
[2764-30] [2764-30] |
8 KB 8 KB |
D D |
TMA-1 TMA-1 |
Download | On ROM sticker is "62-2764-003, Rev C U1101". Content includes "EPROM VER 1.9" On ROM sticker is "62-2764-004, Rev A U1103" |
| Eagle Computer | CGA card for PC Spirit |
? | B | U401 | Font | 0B40D5 | [2764] | 8 KB | D | SomeGuy | Download | On ROM sticker is "Eagle Computer 62-2746-006 Rev B Copyright 1983 U401" | |
| Eagle Computer | 1600 model 1630 |
IBM PC clone | '84 | 2.2 | U403 U404 |
BIOS BIOS |
077AC4 071907 |
[2732] [2732] |
4 KB 4 KB |
D D |
SomeGuy SomeGuy |
Download | Even ROM. On ROM sticker is "62-2732-001, Rev E U403". Odd ROM. On ROM sticker is "62-2732-002, Rev E U404" |
| Eagle Computer | PC-2 | IBM PC clone | '86 | 2.812 | U1101 | BIOS | 0E8100 | [2764] | 8 KB | D | SomeGuy | Download | The BIOS reports itself as "BIOS VERSION 2.812" |
| Eagle Computer | CGA card for PC-2 |
? | U401 | Font | 0ACF7D | MBM2732A-25 | 4 KB | D | SomeGuy | Download | On ROM sticker is "CLR CHAR GEN CF70" | ||
| Everex | EV-391 | 8-bit MFM controller | '84 | 3.92 | U14 | BIOS | 1BA900 | [2764] | 8 KB | D | modem7 | Download | Card design licenced from WD, or WD made the card - click here |
| Everex | EV-346 | 16-bit MFM controller | '88 | 3.2 | U6 | ? | 136DF3 | [2764] | 8 KB | D | modem7 | Download | On ROM sticker is "346-6 VER 3.2" |
| Everex | EV-657 | 8-bit VGA card | '86 | 1.30 | ? | BIOS | 2CE700 | [27256] | 32 KB | D | SomeGuy | Download | |
| Future Domain | [varies] | SCSI controller | '93 | 3.2 | BIOS | 113C00 | [2764] | 8 KB | D | bbuchholtz | Download | For applicability, see here. Normal SCSI ID order. Contains "1800/18C50 SCSI ROM BIOS v3.2" | |
| Future Domain | [varies] | SCSI controller | '94 | 3.4 | BIOS | 108FCB | [2764] | 8 KB | D | bbuchholtz | Download | For applicability, see here. Reverse SCSI ID order, support large disk. Contains "SCSI ROM BIOS for 18C30/18C50/1800 v3.4" | |
| Future Domain | [varies] | SCSI controller | '95 | 3.5 | BIOS | 0FDEBD | [2764] | 8 KB | D | bbuchholtz | Download | For applicability, see here. Reverse SCSI ID order, support large disk. Contains "SCSI ROM BIOS for 18C30/18C50/1800 v3.5" | |
| Future Domain | [varies] | SCSI controller | '88 | 4.0I | BIOS | 10F366 | [2764] | 8 KB | D | IdeaFix | Download | For applicability, see here. Contains "SCSI Disk Drive ROM BIOS V4.0I" | |
| Future Domain | [varies] | SCSI controller | '90 | 6.01 | BIOS | 10CBFF | [2764] | 8 KB | D | bbuchholtz | Download | For applicability, see here. Contains "SCSI Disk Drive ROM BIOS V6.01" | |
| Future Domain | [varies] | SCSI controller | '90 | 7.0 | BIOS | 109C00 | [2764] | 8 KB | D | evris80 | Download | For applicability, see here. Contains "SCSI ROM BIOS 950 AT V7.0" | |
| Future Domain | [varies] | SCSI controller | '93 | 8.2 | BIOS | 125D00 | [2764] | 8 KB | ? | Robin4 | Download | For applicability, see here. Contains "950 SCSI ROM BIOS v8.2" | |
| Future Domain | [varies] | SCSI controller | '94 | 8.4 | BIOS | 10F900 | [2764] | 8 KB | D | bbuchholtz | Download | For applicability, see here. Contains "SCSI ROM BIOS for 9C50/950 v8.4" | |
| Future Domain | [varies] | SCSI controller | '93 | 8.5 | BIOS | 10C400 | [2764] | 8 KB | ? | per | Download | For applicability, see here. Contains "SCSI ROM BIOS for 9C50/950 v8.5" | |
| GSI | 1535 | Floppy controller | '92 | 1.18 | ? | BIOS | 0F4A04 | [28C64] | 8 KB | D | Chuck(G) | Download |
Contains "GSI 1991/2 v1.18 M11" |
| Headstart | LX CD | IBM XT clone | '89 | 2.36 | ? | BIOS | 23E600 | S27C256-15 | 32 KB | D | Dirtbag | Download |
Contains "HEADSTART LX ver. 2.36" and "10/11/89". Zip file contains photos. |
| Hyundai | SUPER-16T | IBM XT clone | '87 | 1.12Ta | U75 | BIOS | 0F4400 | MBM27128-25 | 16 KB | D | sequoia | Download |
|
| Hyundai | SUPER-16TE | IBM XT clone | '89 | 2.00Id | U25 | BIOS | 0F8400 | D27128A-2 | 16 KB | D | sequoia | Download |
|
| IBM | Music Feature Card |
D | ? | Download | Pointer to ibm-pc.org | ||||||||
| IBM | ??? | 8-bit network card (token ring - 16/4 Mbps) |
'88 | ? | U5 U6 |
? ? |
6882D0 5E5E3A |
[27256] D27256-25 |
32 KB 32 KB |
D D |
modem7 modem7 |
Download Download |
25F9443 / ODD byte 25F9444 / EVEN byte |
| IBM | MDA/CGA | Display adapters | ? | ? | ? | Font | 06DDC0 | [MK36000] | 8 KB | C | modem7 | Download | IBM part number on chip is 5788005 |
| IBM | EGA | Display adapter | '84 | ? | U44 | BIOS | 14FC00 | [27128] | 16 KB | D | modem7 | Download | IBM part number on chip is 6277356. See note 1. |
| IBM | PGC | Display adapter | '84 | ? | U43 U44 |
? ? |
367000 2DB300 |
[27256] [27256] |
32 KB 32 KB |
D D |
per per |
Download Download |
IBM part number on chip is 6137322 IBM part number on chip is 6137323 |
| IBM | " | " | '85 | ? | U43 U44 ? |
? ? Font |
349200 2DA700 0D678F |
[27256] [27256] [27256] |
32 KB 32 KB 32 KB |
? ? ? |
Roman Roman Roman |
Download Download Download |
IBM part number of 59X7354 IBM part number of 59X7355 |
| IBM | Display Adapter (VGA) |
Display adapter | '86 | ? | ? | BIOS | 212900 | [27256] | 32 KB | C | Great Hierophant | Download | First 8 KB unused |
| IBM (Xebec) | Fixed Disk Adapter variation #1 |
8-bit MFM controller | '82 ? |
12J 9A |
1. BIOS 2. ???? |
1B2B00 078770 |
[MK36000] [2732] |
8 KB 4 KB |
C D |
modem7 modem7 |
Download Download |
1. IBM part number on chip is 5000059 (same contents as 6359121 chip on later version of card). 2. This chip has "104648D" on it. |
|
| IBM (Xebec) | Fixed Disk Adapter variation #2 |
8-bit MFM controller | '82 ? |
12D 12A |
1. BIOS 2. ???? |
1B2B00 0718DA |
[MK36000] AM2732DC |
8 KB 4 KB |
C D |
modem7 modem7 |
Download Download |
1. IBM part number on chip is 6359121 (same contents as 5000059 chip on earlier version of card). 2. On ROM sticker is "104839E". |
|
| IBM (Xebec) | Fixed Disk Adapter variation #3 |
8-bit MFM controller | '85 '86 |
12D 12A |
1. BIOS 2. ???? |
09EC00 0718DA |
[MK36000] AM2732DC |
8 KB 4 KB |
C D |
modem7 modem7 |
Download Download |
1. IBM part number on chip is 62X0822. 2. On ROM sticker is "104839RE COPYRIGHT XEBEC 1986" (same as 104839E chip on earlier version of card). |
|
| IBM | 4860 (PCjr) | Desktop computer | '83 | 01JUN83 | XX1 ZM63 |
BIOS/BASIC | 33D400 3A9C00 |
MK38050N-25 MK38051N-25 |
32 KB 32 KB |
C C |
mbbrutman mbbrutman |
Download Download |
IBM part number on chip is 1504036 IBM part number on chip is 1504037 |
| IBM | 5140 | Laptop computer | '85 | 13SEP85 | ? ? |
BIOS/BASIC BIOS/BASIC |
3B7F00 32FD00 |
[27C256] [27C256] |
32 KB 32 KB |
? ? |
per per |
Download Download |
2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | 5150 | Desktop computer | '81 | 04/24/81 | U33 | BIOS | 0E8600 | [MK36000] | 8 KB | ? | ? | Download | U33 = 5700051 MD5: 6338A9808445DE12109A2389B71EE2EB |
| IBM | " | " | '81 | 10/19/81 | U33 | BIOS | 0E8600 | [MK36000] | 8 KB | C | modem7 | Download | U33 = 5700671 MD5: 6A1ED4E3F500D785A01FF4D3E000D79C |
| IBM | " | " | '82 | 10/27/82 | U33 | BIOS | 0EB000 | [MK36000] | 8 KB | C | modem7 | Download | U33 = 1501476 MD5: F453EB2DF6DAF21EC644D33663D85434 |
| IBM | " | " | '81 | C1.00 | U32 U31 U30 U29 |
BASIC BASIC BASIC BASIC |
0EDE00 0E8900 0F2D00 0E2700 |
[MK36000] [MK36000] [MK36000] [MK36000] |
8 KB 8 KB 8 KB 8 KB |
? ? ? ? |
? ? ? ? |
Download Download Download Download |
U32 = 5700043 MD5: 2686DBC7F261F10D54553C4C5F93A3D5 U31 = 5700035 MD5: 9A3253AD9F1D8213D33E04476E3ED482 U30 = 5700027 MD5: 8B2A0F2EA97D0ADB9C1C834387AAD5D9 U29 = 5700019 MD5: 2AC2E97EDDB3F344641CDD9DC3747F8E |
| IBM | " | " | ? | C1.10 | U32 U31 U30 U29 |
BASIC BASIC BASIC BASIC |
0EF300 0E9700 0F2D00 0E2E00 |
[MK36000] [MK36000] [MK36000] [MK36000] |
8 KB 8 KB 8 KB 8 KB |
? ? ? ? |
? ? ? ? |
Download Download Download Download |
U32 = 5000023 MD5: B086A6980FC5736098269E62B59726EF U31 = 5000022 MD5: 04A285D5DC8D86C60679E8F3C779DCC4 U30 = 5000021 MD5: 5F85FF5EA352C1EC11B084043FBB549E U29 = 5000019 MD5: 69E2BD1D08C893CBF841607C8749D5BD |
| IBM | 5152 | Printer | ? | ? | 1B | Font ? | 044484 | [2332] | 4 KB | D | modem7 | Download | Actual 5152, not an Epson MX-80. |
| IBM | 5155 | Desktop computer | Uses a 5160 motherboard (the one with 11/08/82 BIOS) | ||||||||||
| IBM | 5160 | Desktop computer | '82 | 08/16/82 | U18 U19 |
BIOS/BASIC BIOS/BASIC |
3B5100 0E2E00 |
[MK38022P-25] [MK37050N-4] |
32 KB 8 KB |
C C |
MicroCoreLabs MicroCoreLabs |
Download | MD5: C25BF18A021F7C5FD17F2C3968590C51 MD5: 69E2BD1D08C893CBF841607C8749D5BD |
| IBM | " | " | '82 | 11/08/82 | U18 U19 |
BIOS/BASIC BIOS/BASIC |
3B5100 0E2E00 |
[MK38036N-25] [MK37050N-4] |
32 KB 8 KB |
C C |
modem7 modem7 |
Download | MD5: 1A2AC1AE0FE0F7783197E78DA8B3126C MD5: 69E2BD1D08C893CBF841607C8749D5BD |
| IBM | " | " | '86 | 01/10/86 | U18 U19 |
BIOS/BASIC BIOS/BASIC |
4043BE 50BE42 |
[27256] [27256] |
32 KB 32 KB |
D D |
modem7 modem7 |
Download | 2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | " | " | '86 | 05/09/86 | U18 U19 |
BIOS/BASIC BIOS/BASIC |
403619 50B5E7 |
[27256] [27256] |
32 KB 32 KB |
D D |
modem7 modem7 |
Download | 2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | 5162 | Desktop computer | '86 | 04/21/86 | U34 U35 |
BIOS/BASIC BIOS/BASIC |
3888C5 38E73B |
[27256] [27256] |
32 KB 32 KB |
C C |
ag ag |
Download | 2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | " | " | '83 | ? | U37 | Keyboard controller |
027403 | 8042 or 8742 | 2 KB | Download | Keyboard controller chip on motherboard. IBM part number 1503033; same as corresponding chip on IBM 5170. | ||
| IBM | 5170 | Desktop computer | '84 | 01/10/84 | U17 U27 U37 U47 |
BIOS/BASIC BIOS/BASIC BIOS/BASIC BIOS/BASIC |
214535 17FD01 21E381 183049 |
[27128] [27128] [27128] [27128] |
16 KB 16 KB 16 KB 16 KB |
D D D D |
fs5500 fs5500 fs5500 fs5500 |
Download | 4 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | " | " | '84 | 01/10/84 | U27 U47 |
BIOS/BASIC BIOS/BASIC |
394236 3A13CA |
[27256] [27256] |
32 KB 32 KB |
D D |
modem7 modem7 |
Download | 2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | " | " | '85 | 06/10/85 | U27 U47 |
BIOS/BASIC BIOS/BASIC |
392971 39738F |
[27256] [27256] |
32 KB 32 KB |
D D |
modem7 modem7 |
Download | 2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | " | " | '85 | 11/15/85#1 | U27 U47 |
BIOS/BASIC BIOS/BASIC |
38A604 38D8FC |
[27256] [27256] |
32 KB 32 KB |
D D |
modem7 modem7 |
Download | 2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | " | " | '85 | 11/15/85#2 | U27 U47 |
BIOS/BASIC BIOS/BASIC |
38A610 38D8F0 |
[27256] [27256] |
32 KB 32 KB |
D D |
modem7 modem7 |
Download | 2 ROMs each carrying part of the overall code/data. Combined 8-bit checksums = 00 |
| IBM | " | " | '83 | ? | U126 | Keyboard controller |
027403 | 8042 or 8742 | 2 KB | D | per | Download | Keyboard controller chip on all three types of 5170 motherboard. IBM part number 1503033 |
| IBM | 5273 | Desktop computer | '85 | U27 U47 |
BIOS/BASIC BIOS/BASIC |
ChrisCwmbran | U27 = 6448896, U47 = 6448897. Same as "11/15/85#2" ROMs for IBM 5170. | ||||||
| InterLan | NP600A-3 | 16-bit network card | |
BA | U38 U39 |
? ? |
0ABEAC 0AA852 |
[2764] [2764] |
8 KB 8 KB |
D D |
modem7 modem7 |
Download Download |
Low byte. "258-0032-00 REV BA" on U38 ROM sticker. High byte. "258-0033-00 REV BA" on U39 ROM sticker. |
| Iomega | Floptical | 8-bit SCSI controller | '92 | V1.0 | U3 | BIOS | 1200 | [27256] | 32 KB | D | Darko | Download | Card for an Iomega floptical drive. "V1.0 01836200" on ROM. BIOS based on Rancho RTBios V-I1.00 BIOS |
| ITT | XTRA | Desktop computer (XT clone) |
'85 | 2.00 | U93 U92 |
BIOS BIOS/DIAGS |
1C4100 22A400 |
[27128] [27128] |
16 KB 16 KB |
D D |
SpidersWeb SpidersWeb |
Download | |
| Jameco | JE1043 | 8-bit floppy controller | '86 | C1 | U26 | BIOS | 06F100 | [2764] | 8 KB | D | Robin4 | Download | This is a relabeled Longshine LCS-6610F. On ROM is "E6610" and "C1". |
| Jameco | " | " | '86 | ? | U26 | BIOS | 06F800 | [2764] | 8 KB | ? | Chuck(G) | Download | This is a relabeled Longshine LCS-6610F |
| JDR | MCT-IDE-8 | 8-bit IDE controller | '93 | 3.30 | U5 | BIOS | 097B00 | M2764A-2 | 8 KB | C | mikey99 | Download |
Centos Inc. model CI-1020. ROM contains string "Centos CI-1020 ROM BIOS Version 3.30" |
| Joincom | JC-1310 | 16-bit MFM controller | '89 | ? | U3 | BIOS | 090ED6 | 2764-20JL | 8 KB | D | Tronix | Download | Contains "(C) COPYRIGHT JOINCOM ELECTRONIC CORP. 9/16/1988 JC1310" |
| Juko | D16X | 8-bit IDE controller | '91 | 1.2 | U5 | BIOS | 6A8113 | [27256] | 32 KB | C | Maxheap | Download | Only 8KB of code. Contains "VERSION 1.2 Copyright 1990, 1991 JUKO" |
| Kaypro | 2000 | Laptop computer | '85 | j.08X | ? | BIOS | 0DCE00 | [2764] | 8 KB | ? | SomeGuy | Download | Contains strings "ROM BIOS FOR KAYPRO 2000 - Ver j.08X" and "ROM BIOS Ver 1.08" !!! |
| Key Tronic | 101WN63S-36E | XT/AT switchable keyboard | '95 | ? | 3 | ? | 040420 | P8049AH | 2 KB | D | modem7 | Download | |
| Key Tronic | KB3270/PC | 3270 keyboard for PC/XT/AT | ? | ? | ? | ? | 05395B | ? | 8 KB | ? | per | Download | Second half is empty |
| Key Tronic | KB3270 Plus | 3270 keyboard for XT/AT | ? | ? | ? | ? | 08FAEC | [27C64] | 8 KB | D | CharlesM | Download | ROM label is marked "55524" |
| Konan | KDC-230 | 8-bit MFM controller | '86 '85 |
PHX150G PHX110B1 |
U17 U11 |
1. BIOS 2. ???? |
0C2600 0C2376 |
MMC27C64Q [2764] |
8 KB 8 KB |
D D |
modem7 modem7 |
Download Download |
On ROM sticker is "KONAN KDC230 PHX150G" On ROM sticker is "PHX110B1" |
| Kouwell | KW-530D | 8-bit floppy controller | '87 | ? | U10 | BIOS | 0B6700 | [2764] | 8 KB | D | Robin4 | Download | BIOS by Joincom Electronic Corp. |
| Kouwell | " | " | '86 | 1.01 | U10 | BIOS | 048800 | [2764] | 8 KB | C | alecv | Download | BIOS by DTK |
| Laser | [ see VTech ] | [ see VTech ] | |||||||||||
| Leading Edge | Model M | IBM PC clone | '84 | 3.30 | ? | BIOS | 1F2970 | [27128] | 16 KB | D | hupshall | Download | Contains "VER. 3.30" |
| Leading Edge | " | " | '86 | 4.71 | ? | BIOS | 1F4D26 | MBM27128-25 | 16 KB | D | ldkraemer | Download | This later version required to support EGA cards |
| Lestina ? | ??? | 16-bit VGA card | '91 | B | ? | BIOS | 44C6DE | [27256] | 32 KB | D | prime | Download | See note 12. Click here to see the bytes rearrranged. |
| Longshine | LCS-6210C REV:G | 8-bit MFM controller | U30 | BIOS | 0D25D9 | M5L2764K | 8 KB | D | modem7 | Download | On ROM sticker is "85005 73B" | ||
| Longshine | LCS-6210D REV:A1 | 8-bit MFM controller | '88 | I2 | U14 | BIOS | 0CF300 | [2764] | 8 KB | D | modem7 | Download | Strings within: "LCS6210D ASIC I2.1 09/01/1988" and "Version I2" / On ROM sticker is "E6210 I2" |
| Longshine | LCS-6210D REV:E | 8-bit MFM controller | '88 | G7 | U27 | BIOS | 0CA800 | [2764] | 8 KB | D | modem7 | Download | Strings within: "LCS6210C G7.0 05/09/1988" and "Version G7" / On ROM sticker is "E6210 G7" |
| Longshine | LCS-6220 (old) | 8-bit MFM controller | '86 | F0 | U23 | BIOS | 0D4000 | D2764D | 8 KB | D | modem7 | Download | Old version of LCS-6220 (long card) / On ROM sticker is "E6220 F0" |
| Longshine | LCS-6220 REV:A3N | 8-bit MFM controller | '89 | U6 | U24 | BIOS | 079D00 | [2764] | 8 KB | D | modem7 | Download | A string within: "LCS6610F REV:U6" / On ROM sticker is "E6610 U6" |
| Longshine | LCS-6610F REV:B | 8-bit floppy controller | '86 | B | U26 | BIOS | 063C00 | TMS2764-20JL | 8 KB | D | Robin4 | Download | A string within: "COPYRIGHT (C) 9,1986 BY LONG SHINE ELECTRONIC CO" / On ROM sticker is "E6610 B" |
| Longshine | LCS-6821N REV:B2 | 8-bit SCSI controller | '90 | 1.04 | U2 | BIOS | 083400 | S27C64A-20 | 8 KB | D | alecv | Download | Contains: "LCS-6821N SCSI Adapter ROM BIOS version 1.04" / Does not support HDDs larger than 512 MB |
| Magitronic | B215 | 8-bit floppy controller | ? | 9.10 ? | ? | BIOS | 1AA600 | ST2764A-20 | 8 KB | D | SomeGuy | Download | Contains "SUNTEK SUN-4300 FDC V-UMC 9.10" |
| Micro Byte | PC230 | IBM XT clone | '88 | 2.12 | ? | BIOS | 34CF00 | NMC27C256Q | 32 KB | D | 3pcedev | Download | Contains "PC230 system BIOS version 2.12, dated 14/11/88" |
| Micro Solutions | CompatiCard IV | 8-bit floppy controller | '92 | 1.05 | ? | BIOS | 0C3000 | S27C64A-15 | 8 KB | D | haglebu | Download | Contains "CC4v1.05" and "Copyright 1992 by Micro Solutions, Inc." |
| Micro Q | Multi Unique FDC | 8-bit floppy controller | '90 | 4.2 | U2 | BIOS | 336600 | HN4827128G-25 | 16 KB | D | modem7 | Download | 8 KB sized code repeated twice. Contains "FDC-344 UNIQUE FDC Firmware Version 4.2" |
| Midiman | MM-401 | 8-bit MIDI interface | '93 | 1.15 | U5 | ? | 10C2D7 | TMS-27C64-25JL | 8 KB | D | Robin4 | Download | Contains strings "Copyright 1991-1993" and "ROM Version 1.15" |
| NCL | NDC-5027 | 8-bit MFM controller | '85 | CN-12-01 ? | C1 C6 |
1. BIOS 2. Microcode |
0D6900 12F8E4 |
M5L2764K M5L2764K |
8 KB 8 KB |
D D |
haglebu haglebu |
Download Download |
On ROM sticker: "NCL 5027 CN-12-01" On ROM sticker: "NCL 5027 00-00-04" |
| NCL | NDC5127 | 8-bit MFM controller | '85 | CN-17-01 ? | E4 E2 |
1. BIOS 2. Microcode |
0D6200 14C4E8 |
M5L2764K M5L2764K |
8 KB 8 KB |
D D |
modem7 modem7 |
Download Download |
On ROM sticker: "NCL 5027 CN-17-01" On ROM sticker: "NCL 5127 01-01-04" |
| Novell | Disk Coprocessor | Special HDD controller | '86 | 817-186-001 Rev E |
U3.2 | ? | 085800 | 2764-25JL | 8 KB | D | modem7 | Download | Under EPROM, PCB has "2764 or 27128" on it |
| NSI Logic | Smart EGA Plus | 8-bit EGA card | '87 | 1.45 | U21 | BIOS | 15E200 | MBM27128-20 | 16 KB | D | per | Download | Main chip: EVC315 |
| Oak | ??? | 8-bit VGA card | '90 | ? | U14 | BIOS | 2C1E00 | [27256] | 32 KB | D | alecv | Download | Maybe version Dv2.15-35 due to the ROM content of "VGA BIOS Dv2.15-35". Main chip: OTI037C |
| Oak | ??? | 8-bit VGA card | '90 | ? | ? | BIOS | 2DD47C | M27256-2 | 32 KB | D | alecv | Download | Maybe version Cv2.15-35 due to the ROM content of "VGA BIOS Cv2.15-35". Main chip: OTI037C |
| Oak | VGA-KO77 | 16-bit VGA card | '92 | V1.06 | U23 | BIOS | 30A200 | [27256] | 32 KB | D | prime | Download | Contains "OAK TECHNOLOGY, INC., VGA BIOS V1.06 (SWLS)". |
| Octek | ??? | 16-bit VGA card | '89 | ? | ? ? |
BIOS BIOS |
551800 553300 |
[27256] [27256] |
32 KB 32 KB |
D D |
prime prime |
Download Download |
High ROM. PCB is labelled "BIOS HIGH". Low ROM. PCB is labelled "BIOS LOW". |
| Octek | ??? | 16-bit VGA card | '90 | ? | ? ? |
BIOS BIOS |
553800 55CC00 |
[27256] [27256] |
32 KB 32 KB |
D D |
prime prime |
Download Download |
High ROM. PCB is labelled "BIOS HIGH". Low ROM. PCB is labelled "BIOS LOW". |
| Olivetti | M15 Plus | Desktop computer | '88 | 1.10 | ? | BIOS | 595AA6 | [27C256] | 32 KB | D | AndrewNi | Download | Contains "06/03/88" and "1.10 Copyright (c) Hitachi, Ltd. 1985" |
| Olivetti | M24 | Desktop computer | '84 | 1.1 | See 'AT&T PC 6300' above | ||||||||
| Olivetti | " | " | '86 | 1.43 | 6F 6H |
BIOS BIOS |
0BDE95 0C776B |
[2764] [2764] |
8 KB 8 KB |
C C |
Thrashbarg Thrashbarg |
Download Download |
High ROM Low ROM |
| Olivetti | " | " | '87 | 1.44 | 6F 6H |
BIOS BIOS |
0BEB1A 0C69E6 |
[2764] [2764] |
8 KB 8 KB |
C C |
[ here ] | Download Download |
High ROM Low ROM |
| Olivetti | M240 | Desktop computer | '87 | 2.04 | ? ? |
BIOS BIOS |
1037F0 106510 |
[27128] [27128] |
16 KB 16 KB |
? ? |
macekmacek macekmacek |
Download Download |
High ROM Low ROM |
| Philips | :YES | Computer | ? | Svenska | Download | Pointer to the Vintage Computer Federation Forums | |||||||
| Plus | Hardcard | HDD-on-a-card | D | ? | Download | Pointer to ibm-pc.org | |||||||
| Priam | InnerSpace | 8-bit MFM controller | '85 | 1.0 | U14 | BIOS | 066A00 | [2732] | 4 KB | D | James191145 | Download | "704055 EC 10372 REV A 60326" on ROM sticker. See note 8. |
| Quadtel | [ ROM ] | VGA BIOS ROM | '92 | 2.13.01 | - | BIOS | 2B4900 | [27256] | 32 KB | D | per | Download | Contains "Quadtel S3 86C801/86C805 Enhanced VGA BIOS. Version 2.13.01" See note 11. |
| Rancho | RT1000B | 8-bit SCSI card | '92 | 8.10R | U3 | BIOS | 0D9B00 | M2764A | 8 KB | ? | Cloudschatze | Download | Manual and software are here |
| Rancho | " | " | '93 | 8.20R | U3 | BIOS | 0F1300 | [2764] | 8 KB | ? | IBM Portable PC | Download | Manual and software are here |
| Samsung | Samtron 88S | IBM XT clone | '87 | 2.0A | ? | BIOS | 330700 | TMS 27C256 | 32 KB | D | modem7 | Download | BIOS by Award / Motherboard contains on-board video, floppy controller, etc. / "701058-06" on ROM |
| Seagate | ST01 - early | 8-bit SCSI controller | 1.7 | 8 KB | From documentation: "Early versions of the ST01 have an 8K ROM and no auxiliary drive power connector." | ||||||||
| Seagate | ST01 - late | [ use ROM for ST02 ] | 16 KB | [ use ROM for ST02 ] | |||||||||
| Seagate | ST02 | 8-bit SCSI/floppy controller | '90 | 3.2 | ? | BIOS | 0DB6DB | [27128] | 16 KB | ? | ? | Download | See note 5. |
| Seagate | " | " | '91 | 3.3 | ? | " | 0DBF00 | " | " | D | alecv | Download | |
| Seagate | " | " | '91 | 3.3.2 | ? | " | 0FF400 | " | " | ? | ???? | Download | * Actually "SyDOS SCSI BIOS REVISION 3.3.5", based on Seagate BIOS version 3.3.2 * Quote from z80eu: "and it supports big HDDs (above 500MB) as well." |
| Seagate | ST10 | 8-bit MFM controller | '87 | 2.4 | ? | BIOS | 0C2C00 | [2764] | 8 KB | D | modem7 | Download | A string within: "ST10 BIOS v2.4". Seagate appear to have licenced the card design from DTC - click here |
| Seagate | ST11R (dual ROM) |
8-bit RLL controller | '88 '88 |
1.5 1.5 |
? ? |
1. BIOS 2. Microcode |
1719DD 0D3A24 |
[27C128] [27C64] |
16 KB 8 KB |
D D |
modem7 modem7 |
Download Download |
"ST11 BIOS V1.5 003" on ROM sticker. See note 5. "ST11R MICROCODE V1.5 003" on ROM sticker / ROM ID's itself as a 27C64 |
| Seagate | ST11R (single ROM) |
8-bit RLL controller | '88 | 1.7 | ? | BIOS | 175562 | [27128] | 16 KB | C | alecv | Download | "ST11M/11R BIOS 005 V1.7" on ROM sticker. See note 5. |
| Seagate | " | " | '88 | 2.0 | ? | BIOS | 13CAE8 | [27128] | 16 KB | C | alecv | Download | "ST11M/11R BIOS 001 V2.0" on ROM sticker. See note 5. |
| Seagate | " | " | '88 | 2.0 | ? | BIOS | 13C400 | MBM27128 | 16 KB | D | sequoia | Download | |
| Seagate | ST21M | 16-bit MFM controller | '89 '89 |
1.3 1.7 |
? ? |
1. BIOS 2. Microcode |
135CFD 0C7A00 |
[27C128] [27C64] |
16 KB 8 KB |
D D |
modem7 modem7 |
Download Download |
"ST21/22 BIOS V1.3 003" on ROM sticker. See note 3. "ST21/22 MICROCODE V1.7 007" on ROM sticker / ROM ID's itself as a 27C64 |
| Seagate | ST22M | [ use ROMs for ST21M ] | [ use ROMs for ST21M ] | ||||||||||
| Silicon Valley Computer |
ADP-50L ( for Tandy ) |
8-bit IDE controller | '88 | 2.18T | ? | BIOS | 0EF428 | ? | 8 KB | C | Great Hierophant |
Download | This particular BIOS designed for Tandy 1000 computers. |
| SMC | SMC4003-PC | 8-bit MFM controller | '88 | ? | U30 | BIOS | 0CF300 | M2764 | 8 KB | D | Tronix | Download | |
| Sperry | HT | [ see Leading Edge Model M ] |
Same as Leading Edge Model M | ||||||||||
| Storage Plus | SCSI-AT Rev. R1 | 16-bit SCSI controller | '90 | 6.3U | IC4 | BIOS | 0D6F00 | M2764A-2 | 8 KB | D | SomeGuy | Download | See note 13. Contains: "ASYNCHRONOUS SCSI HOST ADAPTER BIOS, VER 6.3U" |
| Sunix | Sun-3100 | [ See CTT IT-805 ] | [ See CTT IT-805 ] | ||||||||||
| Sunix | Sun-4300 | 8-bit floppy controller | ? | 02/27 | U9 | BIOS | 132C00 | [2764] | 8 KB | D | modem7 | Download | On ROM sticker: "Name 4300" "Version 02/27" |
| Sunix | Sun-6301 ? | 8-bit multifunction card | ? | 7/10 | U13 | BIOS | 136000 | [2764] | 8 KB | D | modem7 | Download | On ROM sticker: "Name 6301" "Version 7/10" |
| Sysgen | Omni-Bridge | 8-bit floppy controller | '89 | 2.00 | ? | BIOS | 06F200 | [2764] | 8 KB | D | Chuck(G) | Download | String within: "Sysgen Omni-Bridge Floppy BIOS v2.00" |
| Techway | Multi Drive II Plus | 8-bit floppy controller | '89 | 2.3 | ? | BIOS | 0DFB00 | [2764] | 8 KB | C | Néstor | Download | Strings within: "Techway Multi Drive II Plus 2.3" "Ver2.3" |
| Toshiba | T1000 | Laptop computer | '88 | V4.10 | IC25 | BIOS | 1ED500 | [27C256] | 32 KB | C | sanders | Download | Contains "T1000 V4.10 TOSHIBA" |
| Toshiba | T1200 | Laptop computer | '87 | V4.00 | ? | BIOS | 2FC700 | AM27C256-20 | 32 KB | D | san | Download | Contains "T1200 V4.00 TOSHIBA" |
| Toshiba | T2100 8086 | Laptop computer | ? | 004B | ? | BIOS | 1E9B00 | TC57256D-20 | 32 KB | C | pavery | Download | The version of T2100 that has an 8086 CPU |
| Toshiba | T3100e | Laptop computer | '89 | 3.00 | ? | BIOS | ? | ? | MikeS | Download | Two ROMs (high and low) / Combined contents contains "T3100e V3.00" / Combined 8-bit checksums = 00 | ||
| Toshiba | T5200C | Laptop computer | '89 | 3.00 | ? | BIOS | 00 | TMS27C210-20JL | 128 KB | D | modem7 | Download | T5200C = colour version of T5200 / ROM contents contains "T5200 V3.00" / On ROM sticker is "006A" |
| Transteque | HC-100 REV A | 8-bit MFM controller | '86 | A | U15 | BIOS | 055A00 | M5M2764P | 8 KB | C | modem7 | Download | A string within: "TRANSTEQUE HARD DISK CONTROLLER HC-100 REV. A" |
| Transteque | HC-100 REV C2 | 8-bit MFM controller | '89 | 2.03 | U7 | BIOS | 098900 | 27C64A-25 | 8 KB | D | alecv | Download | A string within: "Ver.2.03" |
| Trantor | T128 | 8-bit SCSI card | '90 | 1.12 | ? | BIOS | 114900 | NMC27C64N-150 | 8 KB | D | Robin4 | Download | A string within: "SCSI BIOS, Version 1.12 Copyright (C) 1989-90" |
| Trantor | T130B | 8-bit SCSI card | '92 | 2.14 | U4 | BIOS | 144100 | [2764] | 8 KB | D | modem7 | Download | |
| Trident | [ ROM ] | VGA BIOS ROM | '91 | D2.11 | BIOS | 2BA500 | [27256] | 32 KB | D | alecv | Download | See note 12. Contains "TRIDENT TVGA BIOS D2.11" and "05/16/91". Main chip: TVGA9000A | |
| Trident | [ ROM ] | VGA BIOS ROM | '91 | D3.0 | BIOS | 2EB700 | [27256] | 32 KB | D | romanon | Download | See note 12. Contains "TRIDENT TVGA BIOS D3.0" and "11/12/91". Main chip: TVGA9000i | |
| Trident | [ ROM ] | VGA BIOS ROM | '93 | D3.51 | BIOS | 2DF500 | [27256] | 32 KB | D | sergey | Download | See note 12. Contains "TRIDENT TVGA BIOS D3.51" and "04/12/93". Main chip: TVGA9000i | |
| Trident | [ ROM ] | VGA BIOS ROM | '93 | D4.01E | BIOS | 2E2400 | [27256] | 32 KB | D | sergey | Download | See note 12. Contains "TRIDENT TVGA BIOS D4.01E" and "10/18/93". | |
| Trident | [ ROM ] | VGA BIOS ROM | '93 | C4.4 | BIOS | 2F0F00 | [27256] | 32 KB | D | modem7 | Download | See note 12. Contains "TRIDENT TVGA BIOS C4.4" and "12/13/93". Main chip: TVGA9000C | |
| Trident | [ ROM ] | VGA BIOS ROM | '94 | C4.5 | BIOS | 2F2300 | [27256] | 32 KB | D | romanon | Download | See note 12. Contains "TRIDENT TVGA BIOS C4.5" and "01/28/94". Main chip: TVGA8900D | |
| Tseng Labs | ??? | 8-bit VGA card | '89 | 8.01 | ? | BIOS | 00114E | [27C256] | 32 KB | D | fikus8 | Download | Contains "02/23/89 V8.01X" and "(c)1988 Tseng Laboratories, Inc." |
| Tseng Labs | ??? | 16-bit VGA card | '90 | 1.1 | 1E/1G | BIOS | 2B3A00 | NMC27C256Q-20 | 32 KB | D | modem7 | Download | Contains "VGA-4000 BIOS V1.1" and "Tseng Laboratories, Inc." |
| Vendex | Turbo 888 XT | IBM XT clone | '87 | 2.03A | U25 | BIOS | 002BB000 | [27128] | 16 KB | D | chjmartin2 | Download | Contains "ROM BIOS Ver 2.03A" |
| Vendex | " | " | '87 | 2.03C | U25 | BIOS | 002B9400 | [27128] | 16 KB | D | chjmartin2 | Download | Contains "ROM BIOS Ver 2.03C" |
| Video Seven | VEGA VGA | 8-bit VGA card | '88 | 1.47 | U15 | BIOS | 2B8600 | NMC27C256Q-250 | 32 KB | D | modem7 | Download | FCC ID: D2A62L1989V5 / On ROM sticker: "435-0016-47" / Contains "VEGA VGA BIOS Version 1.47" |
| Video Seven | VGA-16 | 16-bit VGA card | '88 | 1.09 | U16 U17 |
BIOS BIOS |
0BFA9C 2957A4 |
[27128] [27256] |
16 KB 32 KB |
D D |
modem7 modem7 |
Download Download |
"435-0030-09" on chip. Under EPROM, PCB has "16Kx8" on it. "435-0029-09" on chip. Under EPROM, PCB has "32Kx8" on it. |
| Video Seven | VGA 16E | 16-bit VGA card | '89 | 1.14 | ? ? |
BIOS BIOS |
1504B5 154F7C |
[27256] [27256] |
32 KB 32 KB |
D D |
prime prime |
Download Download |
Odd ROM Even ROM |
| Video Seven | VGA 1024i | 16-bit VGA card | '90 | 1.09 | U16 U17 |
? BIOS |
19280C 322900 |
[27C128] [27C256] |
16 KB 32 KB |
D D |
SomeGuy SomeGuy |
Download Download |
|
| VTech | Laser Turbo XT | IBM XT clone | '87 | V1.11 | U20 | BIOS | 0DEA00 | [27C64] | 8 KB | D | 3pcedev | Download | Contains "BIOS V1.11" |
| VTech | Laser XT/3 | IBM XT clone | '89 | V1.26 | ? | BIOS | 0DCC00 | NMC27C64Q | 8 KB | D | Robin4 | Download | Contains "BIOS V1.26". According to Robin4, there are two ROMs, both with identical content. |
| Wang | PC 250/16 | Desktop computer (AT clone) |
'91 | 03.13.00 | L46 L47 |
BIOS BIOS |
55C500 54CA00 |
S27C256-15 S27C256-15 |
32 KB 32 KB |
C C |
Krille Krille |
Download Download |
Chip labelled "9515 ROH". HI chip (ODD). [Wang BIOS 03.13.00, based on a Phoenix BIOS] Chip labelled "9514 ROL". LO chip (EVEN). |
| Wang | 3050 ? | 16-bit VGA card | '91 | 1.02.00 | L18 | BIOS | 3FA000 | S27C256-12 | 32 KB | D | prime | Download | Contains "WVGA-16HR VGA BIOS Version 1.02.00" |
| Wave Mate | ??? | 8-bit VGA card | '89 | 1.21.00 | ? | BIOS | 210A00 | [27256] | 32 KB | D | prime | Download | Contains "Quadtel VGA BIOS Version 1.21.00" |
| WCT | NT-200B | 16-bit VGA card | '89 | ? | U23 U24 |
BIOS BIOS |
15CFE4 15661E |
[27128] [27128] |
16 KB 16 KB |
D D |
modem7 modem7 |
Download Download |
Low byte. Under EPROM, PCB has "27128" on it. High byte. Under EPROM, PCB has "27128" on it. |
| Western Digital | ??? | 8-bit VGA card | '88 | 3056-002 ? | U14 | BIOS | 25CF00 | [27256] | 32 KB | D | alecv | Download | FCC: DBM5UEPS2V00001 Main chip: PVGA1A |
| Western Digital | ??? | 8-bit VGA card | '88 | 3056-007 ? | U14 | BIOS | 247D00 | [27256] | 32 KB | D | prime | Download | FCC: DBM5UEPS2V00001 Main chip: PVGA1A |
| Western Digital | WD1002-27X | 8-bit RLL controller | '86 | ? | U12 | BIOS | 1BA300 | [2764] | 8 KB | D | modem7 | Download | "62-000089-030" on ROM sticker |
| Western Digital | " | " | '88 | ? | U12 | BIOS | 0B5C00 | [2764] | 8 KB | D | SunDown79 | Download | "62-000274-032" on ROM sticker |
| Western Digital | WD1002-WX2 | 8-bit MFM controller | '85 | ? | U36 | BIOS | 0BC100 | [2732] | 4 KB | D | SomeGuy | Download | Custom ROM for IDEA solution. Used with a Tandon TM502. |
| Western Digital | WD1002A-27X | 8-bit RLL controller | '87 | ? | U8 | BIOS | 191A00 | [2764] | 8 KB | C | romanon | Download | "62-000215-060" on ROM sticker |
| Western Digital | WD1002A-FOX | 8-bit floppy controller | '87 | 1.0 | U14 | BIOS | 19D100 | ? | 8 KB | ? | Chuck(G) | Download | |
| Western Digital | WD1002A-WX1 | 8-bit MFM controller | '86 | ? | U12 | BIOS | 0BA700 | [2764] | 8 KB | D | SomeGuy | Download | "62-000094-032" on ROM sticker. This is an 'F300' BIOS. 62-000094-002 has the same content. |
| Western Digital | " | " | '85 | ? | U12 | BIOS | 0BB900 | [2732] | 4 KB | D | MauriceH | Download | Unknown version/revision. Zip file contains comments and photo. |
| Western Digital | WD1002S-WX2 | 8-bit MFM controller | '85 | ? | U14 | BIOS | 0BC300 | [2732] | 4 KB | D | modem7 | Download | "62-000042-11" on ROM sticker. (62-000042-011) |
| Western Digital | " | " | '85 | ? | U14 | BIOS | 1BA000 | MBM2764 | 8 KB | D | haglebu | Download | "ASD2-0" on ROM sticker. Same as 62-000042-013 |
| Western Digital | WD1002S-WX2A | 8-bit MFM controller | '84 | ? | ? | BIOS | 1BA000 | [2764] | 8 KB | D | haglebu | Download | "62-000042-013" on ROM sticker |
| Western Digital | WD1004A-27X | 8-bit RLL controller | '88 | ? | ? | BIOS | 0B9900 | ? | 8 KB | C | romanon | Download | |
| Western Digital | WD1007V-SE1 | 16-bit ESDI controller | '89 '89 |
A5 ? |
U3 U14 |
BIOS BIOS |
12ED00 2B3500 |
[27128] [27128] |
16 KB 16 KB |
D | modem7 | Download Download |
"62-000318-031" on ROM sticker. A string within: "REV. A5 WD1007V" "62-000279-061" on ROM sticker. A string within: "BIOS Utilities" |
| Xebec | 1046838 | SASI bridge | ? | ? | ? | ? | 059AF3 | [2732] ? | 4 KB | ? | SomeGuy | Download | Found in an Eagle 1600 computer |
| Xebec | 1210C | 8-bit MFM controller | '83 '86 |
2.15 104868C ? |
U2 U44 |
1. BIOS 2. CPU |
17F500 167938 |
D2764A-2 TMS2764JL-45 |
8 KB 8 KB |
D D |
modem7 modem7 |
Download Download |
Addressed at C800:0 / May be corrupt / On sticker: "Mitsubishi Electric FXD J15 2.15" On sticker: "104868C COPYRIGHT XEBEC/86" |
| Xebec | 1220 | 8-bit MFM controller | '84 ? |
104830A ? ? |
5M 3M |
1. BIOS 2. CPU |
1A7A00 0718B2 |
MCM68766 TMS2732A |
8 KB 4 KB |
D D |
shock__ shock__ |
Download Download |
Contains: "COPYRIGHT XEBEC (C) 1984" and "104830A3" |
| Note 1 | The ROM socket is fed inverted address lines. That is why the ROM content is reversed (last byte first, first byte last) compared to how the computer sees it. |
| Note 2 | First two bytes are 55/AA indicating BIOS expansion ROM. Third byte is 20 indicating code size in the 32 KB sized ROM is 16 KB. Therefore we'd expect the 8-bit checksum of the first 16 KB to be 00. The 8-bit checksum of the first 16 KB (addresses 0000h to 3FFFh) is instead FE. Not sure what is going on here. Need to look at what is presented to the PC. |
| Note 3 | First two bytes are 55/AA indicating BIOS expansion ROM. Third byte is 1C indicating code size in the 16 KB sized ROM is 14 KB. That explains why the 8-bit checksum of the entire 16 KB is not 00. As expected, the 8-bit checksum of the first 14 KB (addresses 0000h to 37FFh) is 00. It is interesting to note that the actual code size is greater than 14 KB (take a look). |
| Note 4 | First two bytes are 55/AA indicating BIOS expansion ROM. Third byte is 0C indicating code size in the 8 KB sized ROM is 6 KB. That explains why the 8-bit checksum of the entire 8 KB is not 00. As expected, the 8-bit checksum of the first 6 KB (addresses 0000h to 17FFh) is 00. |
| Note 5 | First two bytes are 55/AA indicating BIOS expansion ROM. Third byte is 0C indicating code size in the 16 KB sized ROM is 6 KB. That explains why the 8-bit checksum of the entire 32 KB is not 00. As expected, the 8-bit checksum of the first 6 KB (addresses 0000h to 17FFh) is 00. It is interesting to note that the actual code size is greater than 6 KB (take a look). |
| Note 6 | First two bytes are 55/AA indicating BIOS expansion ROM. Third byte is 20 indicating code size in the 32 KB sized ROM is 16 KB. Therefore we'd expect the 8-bit checksum of the first 16 KB to be 00. The 8-bit checksum of the first 16 KB (addresses 0000h to 3FFFh) is instead FE. Not sure what is going on here. Need to look at what is presented to the PC. |
| Note 7 | The system board appears to be designed to take either one 4KB ROM in socket A49, or two 2KB ROMs in sockets A49/A50. There are links for that, and links to accommodate certain different types of ROM. My 912B has a single 4KB ROM in socket A49, a MM52132, which from a reading perspective, is the same as a 8332 ROM. By modification, I successfully used a TMS2532 in the A49 socket. To do that, after burning, I took pin 21 high, which can be done by either of the following: 1. Alter links W35/W36; or 2. TMS2532 modification. Photo here. |
| Note 8 | According to old adverts, Priam released variations of its 'InnerSpace' disk system (e.g. ID20, ID60-XT, ID130, ...) This Priam copyrighted ROM is from a particular variation, one where the controller is a Western Digital model WD1002S-WX2. ROM contents include "InnerSpace ID" and "ROM BIOS Version 1.0" and "Copyright PRIAM Corporation 1985". |
| Note 9 | TMC-830: According to here, the version 7.0 BIOS from the TMC-850M will work. |
| Note 10 | TMC-860M and TMC-885M: According to here, the version 8.2 BIOS from the TMC-850M will work. |
| Note 11 | VGA BIOS ROM from a multiunction card of unknown make and model. |
| Note 12 | First half is EVEN bytes, second half is ODD bytes. |
| Note 13 | Contains two versions of the BIOS: 6.3U and 5.55. |
| Make | Model | Function | Year | Version | Socket | Data Type | Sum | Chip Type | Size | Copy | Source | Link | Description/Comment |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hampden | MCB-1 | Trainer | ? | - | ? | Monitor | 036D0E | [27C16] | 2 KB | D | gslick | Download | Not the MCB-1A |
| TeleVideo | 912 B | VDU terminal | '80 | - - |
A3 A49 |
- - |
021324 07BF7E |
2316E MM52132 |
2 KB 4 KB |
D D |
modem7 modem7 |
Download Download |
A3: ROM type is 2316E (as printed on the PCB). I successfully used a NEC D2716D EPROM. A49: See note 7 above |
